The Hioki 3030-10 is an analog multimeter that measures voltage, current and resistance, with robust construction that withstands a 1 meter drop onto a concrete floor. CAT III 600 V Key Features |
Model No. (Order Code)
   Â Â |
 |
Simple, easy-to-read scale
|
|---|---|
 |
Robust design that can withstand being dropped onto concrete from a height of 1 m
|
 |
Included carrying case designed to hold probes
|
Basic specifications (Accuracy guaranteed for 1 year, Post-adjustment accuracy guaranteed for 1 year)
Â
| DC Voltage range | 0.3 V (16.7 kÎĐ/V), 3/12/30/120/300/600 V (20 kÎĐ/V) Accuracy: Âą2.5 % f.s. Max. rated voltage: 600 V |
|---|---|
| AC Voltage* range | 12 V (9 kÎĐ/V) Accuracy: Âą4 % f.s. 30/120/300/600 V (9 kÎĐ/V) Accuracy: Âą2.5 % f.s. Average rectifier effective value, Max. rated voltage: 600 V |
| DC current range | 60 ÂĩA/30 m/300 mA (300 mV internal voltage drop) Accuracy: Âą3 % f.s. |
| Resistance range | 0 to 3 kÎĐ (center scale 30 ÎĐ), R Ã 1, R Ã 10, R Ã 100, R Ã 1 k Accuracy: Âą3 % of scale length |
| Battery check | 0.9 to 1.8 V, load resistance 10 ÎĐ, Accuracy: Âą6 % f.s. |
| Temperature scale | Note: The 3030-10 includes a temperature measurement scale, but because the optional Thermister Temperature Probe 9021-01 has been discontinued, the scale is not available for new customers. |
| Power supply | For resistance measurement range, R6P (AA) Ã2 batteries |
| Dimensions and mass | 95 mm (3.74 in) W Ã 141 mm (5.55 in) H Ã 39 mm (1.54 in) D, 280 g (9.9 oz) |
| Accessories | Test Lead L9207-30 Ã1, Spare fuse Ã1, R6P (AA) manganese batteries Ã2, Instruction manual Ã1, Carrying case 9390 Ã1 |
Â
| Catalog: DIGTAL/ANALOG HiTESTER Series | Download PDFÂ [642KB] | English |
